After years of doing 4 links on these vehicles we have perfected it into a kit form so its easy for you to fit at home. Perhaps you are pairing it with one of our Solid axle conversion kits https://www.kinselaskustoms.com.au/products/kun26-solid-axle-conversion?variant=42516974567609 or maybe you are just after more travel or a better ride than the leaf springs can offer. Either way rest assured we have done that hard work so you know it will be easy to fit and work how its supposed to.
There is a few options with our kit;
Springs;
You can run a traditional coil and shock setup which is great for most setups, keeping tray space clear for any water tanks or trundles etc you may have. Most brands are available.
Air bag and shocks are a great way to get an awesome ride, still retaining the clearance under your tray and having an adjustable ride depending on the load (Great for jack off canopies etc)
Coilovers offer premium ride quality once setup well, however can intrude in your tray space as they are quite long.
Coilover and bypass shocks for the most serious setups when you are going to give it a really hard time, whether its just running trails on weekends with a few jumps here and there or for the back of a race car.
Links;
We run alloy links in our kits with either heims on both ends or a bush on one end and a heim the other.
The heims are great for long lasting trouble free movement, however can transfer slightly more vibration through the car when driving as it is a solid joint
Running a bush on one end of the link insulates the vehicle a little more from diff vibrations etc however with lots of articulation these can be prone to wearing out quickly.
Whats included in the kit;
All the weld on brackets you need to complete the job (based on the options you have selected)
Chassis plates,
Link crossmember that supports handbrake and centre bearing
Diff truss with upper link mounts
Lower link mounts with incorporated bump pad
Upper and lower shock mounts (various options below)
Tub floor, low diff mounts with flat top mounts
Tray mounts, hi clearance diff mounts and raised top mounts (can run on a tub but need to cut a hole in the floor)
You can run a 12" King, Radflo, Fox etc on both shock mounting setup along with various other brands. If longer travel is needed other shock mounts can be supplied to suit. Links will cycle a 16" shock.
Brake proportioning valve brackets
Fuel tank mounts with rear Crossmember to 79 series diesel tank
Instructions
Some optional extras we can include are;
Alloy links with heims or bushes
Shocks with springs or Airbags, Coilovers etc
Brake lines
Swaybar to suit.
Fuel lines to relocate the tank
